Chemical Reaction Engineering Lab

In chemical reaction engineering (Also called reaction engineering or reactor engineering), are used different types of reactor for solids dissolution, product mixing, chemical reactions, batch distillation, crystallization, liquid/liquid extraction and polymerization in process industries and for experiment purpose in chemical reaction engineering laboratories.

Equipment List

  1. Continuously Stirred Tank Reactors

    • In an ideal CSTR the contents in reactor are well mixed and have uniform composition throughout. Thus the exit stream has the same, composition as the fluid within the reactor. read more
  2. Plug Flow Reactor

    • In a great Plug Glide Reactor (PFTR) there’s no mixing within the path of go with the flow and full mixing perpendicular to course of float. Focus of reactants varies alongside the size of reactor however no longer in radial course: read more and this.
  3. Isothermal Batch Reactor

    • batch reactor is a closed system with no input and output streams. A batch reactor can operate under conditions like Isothermal (Temperature of Reaction  remains constant), perfectly mixed (composition of reaction mixture is uniform throughout), and constant volume read more
  4. Isothermal Semi-Batch Reactor

    • An isothermal semi-batch reactor is a semi-closed system with one input stream. It is operated under conditions like Isothermal (Temperature of Reaction remains constant) and perfectly mixed (composition of reaction mixture is uniform throughout). read more
  5. Adiabatic Batch Reactor

    • An adiabatic batch reactor is a closed system with no input and output streams. This reactor is operated under conditions like adiabatic (Temperature of Reaction Mass keep on changing), perfectly mixed (composition of reaction mixture is uniform throughout), and constant volume read more
  6. Packed Bed Reactor

    • The setup consists of a glass column packed with Rasching Rings and two feed tanks. Reactants are fed to the reactor through liquid distributor, fitted at the bottom of the column. Rota meters are provided to measure the individual flow of Chemicals. read more
  7. Kinetics Of Dissolution Of Benzoic Acid

    • The setup consists of a Reactor in which solid cylinder of Benzoic Acid is placed and water is stirred by means of a variable speed mixer. Baffles are also provided. The Reactor is made of Stainless Steel. read more
  8. RTD Studies in CSTR

    • Real reactors do not satisfy the idealized flow patterns, back mix flow or plug flow deviation from ideality can be due to channeling of fluid through the vessel, recycling of fluid within the vessel or due to the presence of stagnant region or pockets of fluid in the vessel. read more
  9. RTD Studies in Plug Flow Reactor

    • Real reactors do not satisfy the idealized flow patterns, back mix flow or plug flow deviation from ideality can be due to channeling of fluid through the vessel, recycling of fluid within the vessel or due to the presence of stagnant region or pockets of fluid in the vessel. read more
  10. RTD Studies in Packed Bed

    • The setup consists of a glass column packed with Rasching Rings. Liquid is fed to the reactor through liquid distributor, fitted at the bottom of the column. Rota meter is provided to measure the flow. The flow rate can be adjusted by operating the needle valve provided on Rota meter. read more
  11. Emulsion Polymerization Reactor

    • The set-up consists of jacketed type SS reactor fitted with a variable speed agitator & baffles. Hot water from a digitally controlled water bath is circulated in the jacket using a pump. read more
  12. Condensation Polymerization Reactor

    • Condensation Polymerization kettle is used to carry out a condensation polymerization reaction under batch condition. Polymerization reaction can be acid catalyzed or self-catalyzed. The set-up can be used to measure the extent of reaction &.also the reaction rate constant. read more
  13. Hydrodynamics of Trickle Bed

    • Tile set-up consists of a glass column. Arrangement is made for changing the glass column conveniently and filling it with any type of packing required. Air from a regulated pressure vessel passes through a sparger and allowed to enter in the column at the top. read more
  14. Combined Flow Reactor

    • In a Combined Flow Reactor, the contents are passed through two types of Reactors PFR and CSTR, connected in series. This set-up is used to study a non-catalytic homogeneous second order liquid phase reaction under ambient condition. read more
  15. RTD Studies in Plug Flow Reactor

    • In an ideal Plug Flow Reactor {PFTP} there is no mixing in the direction of flow and complete mixing perpendicular to direction of flow. Concentration of reactants varies along the length of reactor but not in radial direction. read more
  16. UV Photo Reactor
